What Voltage should I go with my Off-Grid Solar System, 12, 24 or 48 Volt?

What Voltage should I go with my Off-Grid Solar System, 12, 24 or 48 Volt?

Why is it Imperative to Dedicate Time to Educate Yourself thoroughly Before making a Solar Equipment Purchase?

  • Navigating Voltage Choices: Lessons from Recent Solar System Design
  • Our top 5 Considerations before choosing Solar System Voltage
  • Conclusion

Navigating Voltage Choices: Lessons from Recent Solar System Design

I recently designed a system that involved upgrading from 12 volts to 24 volts because the customer’s inverter suddenly stopped working. I explained the advantages of transitioning to 24 volts instead of getting another 12-volt inverter charger, and the customer agreed with me. They recognized the overall benefits, including future upgrade capabilities and the potential for a more efficient system. On the same day, another customer called expressing regret for not choosing 24 volts initially. Despite receiving the same information, this customer opted for 12 volts again. The reason for their decision was that they had a 12-volt fridge, and while it’s possible to add a 24 to 12-volt DC to DC charger to work with the fridge while maintaining a 24-volt system, they chose to stick with 12 volts and now wish they hadn’t. This highlights the importance of understanding the differences and available options when making such decisions. In certain situations, like in an RV or camper where most loads are already in 12 volts and roof space for solar is limited, the choice becomes more straightforward. However, some customers, despite the information provided, opt for a 24 or 48-volt system right from the start.

Our top 5 Considerations before choosing Solar System Voltage

The choice of voltage for your off-grid system depends on various factors, and there isn’t a one-size-fits-all answer. Here are some considerations to help you make an informed decision:

1. System Size:

In smaller systems, such as those powering remote temperature-monitoring devices with minimal current requirements or solar-powered small devices, lower voltages like 12V or 24V are often more practical. There’s no imperative reason to opt for higher voltage systems in these scenarios. For instance, in an RV where space constraints limit the number of panels on the roof, a 12V system is a fitting choice. Conversely, larger systems benefit from higher voltages, such as 48V, which help mitigate power losses in wiring and enhance overall efficiency. In the case of larger trailers or RVs with substantial loads like air conditioning units, a 24V system may be preferred, with the option to convert to 12V for specific devices designed for that voltage.

2. Distance and Wiring:

Opting for higher voltages offers the advantage of transmitting power over extended distances with reduced energy loss. This is particularly beneficial when system components are spread out, enhancing overall efficiency. Consider, for instance, small cabins or homes situated in remote areas with sufficient space for larger, potentially heavier batteries. Choosing a higher voltage system not only enables the use of more efficient components but also facilitates savings on larger cables for extended distances, allows for the use of smaller fuses and breakers, and minimizes the strain on batteries through reduced work and cycling.

3. System Efficiency:

Opting for higher voltage systems brings notable efficiency benefits by enabling the utilization of smaller wire sizes, consequently minimizing resistive losses. Additionally, transforming 48 volts DC to 120 or 240 volts AC proves more efficient than converting 12 volts DC to 120/240 AC. This heightened efficiency is attributed to the fact that inverters operating at higher voltages inherently consume less energy during the inversion process. Nonetheless, it’s essential to note that the overall system efficiency hinges on the effectiveness of the individual components you select.

4. Cost:

Evaluate the cost of components across various voltage systems and align it with your budgetary constraints. Keep in mind that the expense for battery storage rises with higher voltages, a pivotal factor to consider. Not only do batteries incur higher costs, but the price of certain inverters designed for elevated voltages also increases. Additionally, as the solar capacity required to effectively charge larger, higher-voltage batteries grows, so does the overall system cost. While opting for higher voltage systems undoubtedly enhances efficiency, it’s essential to acknowledge that this efficiency comes with a corresponding increase in expenses.

5. Future Expansion:

Carefully consider your future expansion objectives when determining the system voltage. Opting for a higher voltage right from the start enhances the flexibility for potential expansions. The potential for system growth is significantly magnified, offering a threefold increase in capacity compared to a 12V system—an aspect that demands thoughtful consideration. While a 12V system serves certain applications, it does have limitations, particularly within the realm of smaller wattage capacities ranging from 500 to 2000 watts, occasionally reaching 3000 watts. With escalating power demands, such as in a 3000-watt system, it is advisable to opt for a minimum of a 24V setup. Notably, systems exceeding 4000 watts are unavailable in 12 volts, and those reaching 7kw to 12kw are exclusively offered in 48 volts. Recognize that higher power handling tends to be less efficient at lower voltages, emphasizing the advantages of contemplating a higher voltage system for expanded capabilities and heightened efficiency. Always prioritize future planning, especially considering the significant investment in establishing your own power. Anticipating cabin expansions or additions like a second room or building in the future is crucial, as these developments will undoubtedly introduce additional power needs over time.

white concrete building near green tree during daytime
caption for image


In conclusion, the voltage choice for your off-grid system is a crucial decision that hinges on a myriad of factors, including system size, equipment availability, wiring considerations, and future expansion plans. Whether opting for 12V, 24V, or 48V, it’s imperative to weigh the pros and cons based on your specific needs. Seeking guidance from renewable energy professionals or experienced electricians is strongly recommended to ensure an informed decision aligning with your unique circumstances.

At IOTG Solar, we are committed to providing comprehensive support for all your solar needs. From initial inquiries to system designs, and access to essential components like batteries, cables, and connections, we stand ready to facilitate a seamless setup. Whether you’re embarking on mobile travels or enjoying the tranquility of your cabin or off-grid home, our expertise is dedicated to ensuring your renewable energy solution is tailored to meet and exceed your expectations. Thinking of a system? Upgrading an existing system? Give us a call or today!
